GENERAL SPECIFICATION
• Operating temperature : -20°C to +55°C
• Solder heat resistance : 350°C for 5 seconds
• Sealing : Panel sealed to IP65, rear of panel IP40
ENVIRONMENTAL SPECIFICATIONS
• Sealing : Panel sealed to IP65, rear of panel IP40
ELECTRICAL SPECIFICATIONS
• Current/voltage rating : 10mA 5VAC min, 6Amp 250VAC, 6Amp 12VDC
• Initial contact resistance : 10m? max at 1Amp 4VDC
• Insulation resistance : 50M? min
• Dielectric strength : 750V between open contacts, 5KV live to accessible • Electrical life 50,000 cycles min
• Insulation : Class 2
• Lamp life : LED, 60,000 hours to 75% relative luminosity filament, approx. 5000 hours,
neon, approx. 10,000 hours
MATERIALS
• Screens : PC
• Reflector assembly : PC
• Nut : ABS
• Camtrack Momentary : PPE
• Camtrack maintained : PPSU
• Switch block 1 & 2 pole : PBT
• Switch block 3 & 4 pole : PEI
• Contacts : Gold plated silver
MECHANICAL SPECIFICATIONS
• Contact gap : >1mm (0.039)
• Mechanical life : Momentary, 1 million cycles, maintained 100,000 cycles • Lamp : Midget grove T1 3/4 filament, neon or LED
• Terminals : Solder/quick connect 2.8mm (0.110)
APPROVALS
UL
